The TBJ Model 25-94-2B SPCS work sink is specifically designed for use in GI Labs and Sterile Processing Departments for the pre-cleaning of flexible endoscopes. The unit includes two sink bowls thus meeting AAMI guidelines for having a minimum of two separate sink basins……one for manual cleaning and leak testing and one for rinsing of scopes. The work sink shall have the following configuration and features:

• Two 28” x 16” x 10 ½” deep sink bowls
• (2) deck mounted hot/cold faucet with wrist blade handles shall be located between sinks.
• The sink top shall be 36” above the finished floor. The OPTIONAL ergonomic, electrically operated hydraulic lift system allowing the sink height to be adjusted from 32” to 40” high via a rocker switch control is included.
• An OPTIONAL deck mounted cold water spray pistol is and air pistol is included/li>
• An OPTIONAL set of (8) tips for the water and air pistol is included.
• Two lever handle drain controls for remote sink draining
• Full length, 12” wide undershelf below sink top for storage
• Overall dimensions: 25” W x 94” L

Construction/Design:

• Heavy duty stainless steel construction
• Type 304 stainless steel sink top, 14 gauge, #4 finish
• Type 304 stainless steel tubular base frame made of 1 ½” square x 16 gauge wall tubing
• Adjustable leveling feet
• Seamless heliarc welded construction
• All exposed welds ground and polished
• 4” high backsplash extending the length of the sink top
• NSF approved 14 gauge sink bowls with cove corners
• 1/8” high marine edge on around front and sides
• Hospital grade, chrome plated brass faucets and fixtures
• Lever handle drain controls
• Sink bowl sizes and overall dimensions can be customized around your specific needs
• A wide variety of optional features are available to add to the base unit. See partial list of optional features listed below
