The TBJ Model 30-117-3B-WS-AH work sink is specifically designed for use in hospital sterile processing departments for the pre-cleaning of grossly soiled surgical instruments, utensils, endoscopes and other miscellaneous items prior to automated washing/disinfection cycles. The unit includes three 30” sink bowls to better accommodate robotic instruments. The work sink shall have the following configuration and features.

• (3) 30” x 16” x 10.5” deep sink bowls with etched gallon indicator markings
• The left sink includes Hydro-force rinse system with pump, adjustable timer, push-button control and on/off switch.
• The center sink includes heated ultrasonic power and control unit and has ultrasonic transducers mounted to underside of sink bowl. (ultrasonic power unit requires 120V electrical). (Bowl 2)
• (3) Pull-up drain controls
• (2) Automatic sink bowl fill with timer and push-button (Bowls 1 and 2)
• (2) Automatic detergent dispensing with push-button pre-sets, soak timer and temperature monitoring (bowls 1 and 2)
• (2) Heated sink bowls with digital thermostat control (Bowls 1 and 2)
• 4” high back splash
• Marine edge around front and side perimeter
• (2) Hot/cold water faucets with swing gooseneck and wrist-blade handles
• (1) Hot/cold water pre-rinse sprayer with wrist-blade handles
• (1) Selecta water pistol
• (1) Selecta air pistol
• (1) Set of (8) pistol attachments for Selecta pistols
• (1) DI/RO pure water faucet
• Push-button height adjustment with 8” travel range
• Optional rigid telescoping drains to accommodate height adjustment
• Under-counter storage shelves provided in movable/removable sections
• Temperature monitor (bowl 3)
• (2) Anchorage brackets (expansion anchor hardware, seismic calculations and OSHPD approval not included)
• Overall dimensions: 30” wide x 117” long

Construction/Design:

• Heavy duty stainless steel construction
• Type 304 stainless steel sink top, 14 gauge, #4 finish
• Type 304 stainless steel tubular base frame made of
  1 ½” square x 16 gauge wall tubing
• Adjustable leveling feet
• Seamless heliarc welded construction
• All exposed welds ground and polished
• 4” high backsplash with sloped top
• NSF approved 14 gauge sink bowls with cove corners
• 1/8” high marine edge on around front and sides
• Hospital grade, chrome plated brass faucets and fixtures
• Lever handle drain controls
• Sink bowl sizes and overall dimensions can be customized
  around your specific needs.
• A wide variety of optional features are available to add to the
  base unit. See partial list of optional features listed below.
